Long Range RFID Reader For Gate Motor Intelligent Barrier Arm Gates

Wonsun is a very reliable company, fast shipment and good quality, the most important is competitive prices.

—— Ali Alabadi

I really recommend, a great team and good quality. Very good. I will buy again.

—— Oliver

Ben sohbet şimdi

Long Range RFID Reader For Gate Motor Intelligent Barrier Arm Gates

Çin Long Range RFID Reader For Gate Motor Intelligent Barrier Arm Gates Tedarikçi

Büyük resim :  Long Range RFID Reader For Gate Motor Intelligent Barrier Arm Gates

Ürün ayrıntıları:

Place of Origin: China
Marka adı: WONSUN
Sertifika: CE, ISO, SGS
Model Number: WSTP-116

Ödeme & teslimat koşulları:

Min sipariş miktarı: 1ADET
Fiyat: negotiation
Packaging Details: Packed in bubble wrap firstly, and then reinforced with carton for outer packing.
Teslim süresi: ödemenizi aldıktan sonra 3-7 iş günü
Ödeme koşulları: T / T, Western Union, Para Gram, Alibaba Ticaret Güvencesi, Paypal vb,
Yetenek temini: 1000 setleri/ay
Contact Now
Detaylı ürün tanımı
Operation Time:: 0.6s, 1s, 1.8s, 3s, 6s, Optional Housing Material:: 2mm Cold Roll Plate Or Galvanized Plate
Product name:: Long Range RFID Reader For Gate Motor Intelligent Barrier Gate Color: yellow, Orange, Black, Blue, customize optional
Brand: WONSUN Arm Length:: 0.6s with 2.5m, 1s with 3m, 1.8s with 3.5m, 3s with 4.5m, 6s with 6m

Long Range RFID Reader For Gate Motor Intelligent Barrier Gate





WONSUN SUMMER PROMOTION: BUY 20 SETS, GET 1 FOR FREE

                               IF INTEREST, PLEASE CONTACT ME FREELY

                               SKYPE: zimin1314

                               Whatsapp: +86 18507481610





Quick details:



1) Beam length: <=6m

2) Opening (Closing) time: 1s, 1.8s,3s, 6s

3) Machine core working temperature: -40 degrees to +75 degrees

4) Electric working temperature: -20 degrees to +75 degrees

5) Rated voltage: AC 220V (10%) 50Hz/60Hz, 110V (10%) 50Hz/60Hz

6) Rated power: 120W

7) Relative humidity: <=90%

8) Remote control distance: <=30m

9) Net weight: 55KGS

10) Package size: 1025*375*470mm





Features as follows:

1) The top of cover is square and it looks elegant.
2) Machine core with compression spring, effectively avoids the accidents caused by spring breaking
3) Die-casting aluminum alloy motor, precision and good at thermal radiating
4) Torque motor,steady,low noise,long life
5) This barrier gate provides optional case color as yellow/orange/white/red/blue
6) This automatic barrier gate provides optional boom arm direction as leftward/rightward
7) This type of barrier could match with direct boom( pole) , fold boom or fence boom.


Functions:


1) Manual release
2) Machine core with compression spring, effectively avoids the accidents caused by spring breaking
3) Die-casting aluminum alloy motor, precision and good at thermal radiating
4) Motor cooling fan, solving the problem of heat-protection
5) Double safety limit switches (photocell electrical limit switch/motor memory sensor)
6) Reversing on obstacle,
Auto-closing
7) Support the INFRARER PHTOCELL for anti-bumping function (optional)
8) Support the external and internal VEHICLE LOOP DETECTOR (optional)
9) Traffic light interface
10) Wire control (switch signal)/ Remote control (418MHZ)
11) RS485 communication module (optional)





Each barrier gate will include:



1 pcs Gate Barrier

1 pcs arm boom (from 1m to 6m can customised)

1 pcs control panel(built inside)

2 pcs remote controllers

1 pcs manual book

1 pair photocell( optional)

1 loop detector( optional)

1 RS485( optional)





Service items


1.One year's free servicing is supplied( not including the arm)
2. Lifetiom charged servicing is offered.
3. Technology servicing is supplied
The following situations are charged for servicing (or changing):
1. Broken by wrong installation.
2 Broken by improper voltae.
3. The surfaces of the system destroyed by wrong installation our use.
4. Broken by natural disaster.
5. Overdue
6. Servicing items out of our promises.
The upgrade and improvement of the product won't be notified if there is any.
The explaining authority of this product instruction and service article belong to the production factory.





FAQ:



1. When barrier finish closing, why does the arm open itself slowly?

  • the spring is too tight, you need release the spring a little, then test it again.
  • see whether the main crank touch the triangle tightly or not, if tightly, adjust it.
  • reset the balance position and the electrical limit switch.

2. Why does the controller panel operate with "Di Di Di" abnormal noises?

  • As for this, it means the resistance on controller board is broken, if you have professional tools to check,
  • then replace that broken resistance, if not, replace that controller panel.

3. Why does the barrier finish half operation of opening and closing?

  • If uses our controller panel, you only need to find resistance R37 on controller panel, and repalce it is ok.

4. When barrier closed, why is there a 5 degree angle of inclination?

  • the model is not good, and the gear doesn't fit each other tightly.
  • the barrier didn't adjust well, need to reset.

5. When barrier finish open, but it closes itself without any order control, what's the problem?

  • To check the loop cable first, because the loop cable maybe brokem
  • To check the motor sensor, if it is not set well, then reset it in the middle between two holes on sensor rod.
